USB Long Tip A Male / 5 PIN Micro Soldering Machine Vibration Plate Automatic Feeding
| Certification | CE |
|---|---|
| Model Number | AM121 |
| Minimum Order Quantity | 1SET |
| Price | Negotiation |
| Packaging Details | Exported Wood Package |
| Delivery Time | 5-10 working days |
| Payment Terms | Western Union, L/C, T/T |
| Supply Ability | 50 sets per moneth |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Power | AC220V | Air Source Pressure | 0.5-0.8MPA |
|---|---|---|---|
| Production/hour | 900-1200PCS | Applicable Wire | 2.6-2.7mm |
| Dimensions | 800*600*1100MM(L*W*H) | Soldering Angle | 90 Degree |
| Soldering Material | Soldering Wire | Mounting | Fall On Ground And Movable |
| Highlight | cable soldering machine,usb cable making machine |
||
Product Description
USB Long Tip A Male / 5 PIN Micro Soldering Machine Vibration Plate Automatic Feeding
Features:
USB automatic tin soldering machine is mainly used for USB wire long tip A male,short tip AM,MIN5PIN,MCRO5PIN welding,automatic feeding by vibration plate, splitting wire, pulling, cutting flat, stripping, welding, etc. The equipment structure is compact, the welding orientation has high speed,high precision characteristics. We use high power welding table, temperature return speed is fast, control the temperature with highly precision, welding effect steadily, completely replacing the industry’s most difficult recruit soldering workers .
Each set machine can solder 1200 PCS wire,it means one general worker can finish the 4 skilled soldering workers’ working amount. Save 150,000RMB (23809 USD) each year.And the products which processed by this machine quality is highly steadily, won’t process cold solder or disturbed soldering, this machine processed products solder joints well-distributed.
Application Range
1) the soldering between USB A Male connector and wire.
2) the soldering between USB B Male connector and wire.
3) the soldering between micro USB connector and wire.
4) the soldering between mini connector and wire.
5) the soldering between iphone connector and wire.
6) the soldering between PCB/Switch and wire.
| Voltage | AC220V/110V |
| Power | 600W |
| Air Pressure | 0.5-0.8MPA |
| Productivity | 800-1200pcs/h |
| Dimension | 800*600*1100MM(L*W*H) |
| Mounting | Moving on ground |
| Temp control model | Constant temperature |
| Soldering material | Soldering wire |
| Soldering angle | 90 degree |
