High Frequency Automatic Brazing Machine 20KW Robotic Arm 8 Seconds Per Piece

  • High Frequency Automatic Brazing Machine 20KW Robotic Arm 8 Seconds Per Piece
Certification CE
Model Number AM151
Minimum Order Quantity 1 Set
Price Negotiation
Packaging Details Packed in wooden box
Delivery Time 30 Days
Payment Terms L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability 2 sets per Month

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Air Pressure 0.5-1.0MPA Voltage AC220V/50Hz
Power Of Main Engine 1.5KW Maximum Power Of Brazing Machine 20KW
Influent Temperature Less Than 40℃ Speed 8 Seconds/piece
Highlight

induction brazing machine

,

induction brazing equipment
Leave a Message
Product Description

High Frequency Automatic Brazing Machine 20KW Robotic Arm 8 Seconds Per Piece​





Introduction
Automatic Brazing Machine is the newest automatic welding machine developed
by our company.This machine apply to welding all kinds of copper work
pieces.The high frequency brazing technique and robotic arm realize the welding
between work pieces. It has advantages of wide range of application, good effect,
high efficiency, cost saving and environmental etc.


Operating Principle
The induction coil will generate strong alternating magnetic field when induction
heating device outputs the electric current flows. Applying a magnetic field, the
surface of work piece will generate vortex current and be heated rapidly. The
soldering flux and material will be added when the work piece is being heated, the
welding processing will finish after the soldering material dissolving and cooling.





Basic Parameters

Air Pressure 0.5-1.0MPA
Voltage AC220V/50Hz
maximum power of main engine 3.4KW
Power of main engine 1.5KW
maximum power of Brazing Machine 20KW
Cooling hydraulic pressure 0.2MPa
Influent temperature less than 40℃
Speed 8 seconds/piece
Dimension 2100mm*900mm*2100mm
Floor space 5020mm*2100mm



We Shenzhen Aituo Automation Device Co., Ltd is a production-oriented high-tech company, which in the field of automation machine and equipment with strong technological, has a strong research&design team.

Our productions mainly are wire terminal processing equipment, which includes: Automatic USB soldering machine, automatic wire strip&tin machine, full/semi automatic cable bundling machine, automatic wire stripping cutting machine, automatic terminal crimping machine, gas wire stripping machine, copper strap machine and so on.

If there is anything you need please feel free to contact me to confirm the detail, our team will make an perfect plan for you!!



High Frequency Automatic Brazing Machine 20KW Robotic Arm 8 Seconds Per Piece 0High Frequency Automatic Brazing Machine 20KW Robotic Arm 8 Seconds Per Piece 1
